Hinge Joint Fence Cattle Fence

Description:

Field Fence(woven-wire) is manufactured in a wide variety of height and styles and feature a gradually spacing that starts with small opening at the bottom, helping to prevent entry by small animals(like chicken, rabbit). The Field Fence allows the fencing to give under pressure and spring back into shape.  It is also expands or contracts under changing weather, giving flexibility and adding strength.   This quality fencing ensures a solid construction over any terrain, Our field fence is designed using a variety of spacing configuration to accommodate horse, cattle, sheep, hogs, deer, and other large animals.

There are three types of knot for Field Fence. Hinge Joint Fence, Fixed knot fence, Square deal knot


  • :
  • Product Detail

    Product Tags

    video

    Product Description

    galvanized-hinge-joint-fence

    HINGE JOINT FIELD FENCE /Cattle Fence/Sheep Fence Field Fence

    Hinge Joint Fence is made of top quality high tensile steel wire, has four wrap knots or joints formed with two vertical stay wires wrap together to form hinged joint knot which acts as a hinge that gives under pressure, then springs back into shape. Vertical wires are individually cut and wrapped for maximum strength and flexibility.

    Hinge Joint Field Fence is utilized for various farm applications including crop protection, livestock confinement, land fencing, and as sideline dividers. It can also be used with erosion control silt fence backing. Due to its strength and reduced risk for sagging and deterioration, it is an ideal solution for preventing animal penetration.

    Additional features include wire tension curve, extra strong top and bottom wire lines, and resistance to cattle impact. It has small bottom mesh spacing to keep small wild animals out and wide upper spacing to keep larger animals and livestock confined and safe.

    cattle fence 01
    hinge-joint-fence
    hinge-joint-fence-finished

    Material

    Low carbon Steel Wire

    High Tensile Steel wire

    Specification

    No.

    Item

    Specification

    The top

    and bottom

    wires

    diameter

    Filler Wire Dia.

    1

    7/150/813

    102+114+127+140+152+178

    2.5-3.0

    2.0-2.5

    2

    8/150/813

    89(75)+89+102+114+127+140+152

    2.5-3.0

    2.0-2.5

    3

    8/150/902

    89+102+114+127+140+152+178

    2.5-3.0

    2.0-2.5

    4

    8/150/1016

    102+114+127+140+152+178+203

    2.5-3.0

    2-2.5

    5

    8/150/1143

    114+127+140+152+178+203+229

    2.5-3.0

    2-2.5

    6

    9/150/991

    89(75)+89+102+114+127+140+152+178

    2.5-3.0

    2-2.5

    7

    9/150/1245

    102+114+127+140+152+178+203+229

    2.5-3.0

    2-2.5

    8

    10/150/1194

    89(75)+89+102+114+127+140+152+178+203

    2.5-3.0

    2-2.5

    9

    10/150/1334

    89+102+114+127+140+152+178+203+229

    2.5-3.0

    2-2.5

    10

    11/150/1422

    89(75)+89+102+114+127+140+152+178+203+229

    2.5-3.0

    2-2.5

    Note: 1. we can also produce the mesh according to customers requirements.

             2. Roll length from 50m-300m, as customer’s requirement.

    Features

    Hinge joint fence.

    Heavy duty galvanized.

    Extra and uniformly zinc coated.

    Wire tension curve.

    Pre-stripped rolls.

    Extra strong bottom and top wire lines.

    Advantages

    Resistant to big animal impacts.

    Extremely weather resistant.

    Bottom mesh gradual spacing prevents small animal from getting in or out the field.

    Easy to install. Saves time, labor and money when installing.

    Durable, Long lasting.

    Application

    1. For ranch, farm: it is ideal for the horse raising, breeding, also for cattle, goat and dog kennels.

    2. Protect the environment: it can prevent grassland, plant and forest from damaged.
